| Dump-Lok steel braces have been proven in lab tests to support up to 50,000 lbs.
Dump-Lok Specifications
Overall Height . . . . . . . . . . . . . . . . . . . 21 in.
Overall Width . . . . . . . . . . . . . . . . . 5.25 in.
Overall Length. . . . . . . . . . . . . . . . 12.75 in.
Weight . . . . . . . . . . . . . . . . . . . . . . 37.5 lbs.
Maximum Capacity (Pairs) . . . . . . . 50,000 lbs.
The Dump-Lok steel braces are strictly intended to be used as a pair.
- Dump-Lok can be used universally on any brand of dump box.
- Dump-Lok can safely hold dump beds at higher angles than manufacturerprops, giving employees safe access to a wider area underneath the dump bed.
- Dump-Lok steel braces fit up to a 4.5 inch flange - the standard dump truck flange is 3.5 inches.
- Dump-Lok is designed with easy to grip handles, making each steel brace easy to carry and easy to install between the truck frame and dump box.
- Dump-Lok fulfill's OSHA's recommendation for employers to protect employees from the hazards faced when working under a raised dump truck dump body by using an alternative "truck bed brace bracket". (OSHA SHIB 09-18-2006)
Click here to see photos of Dump-Lok in action |
